Slide Compound Saw
LS1018LN
1 430 W • 260 mm • 4 300 min⁻¹
Efficient and accurate saw with a laser for high-capacity applications
• Large Cutting Capacity in a Compact Design and Less Weight
• Less weight and compact design for job site portability
• Soft start feature for smooth start-ups
• Ergonomic rubberized D-handle design for better fit and added comfort
• Large precision machined aluminum base supports material for more efficient cutting
• Electric brake for maximum productivity
• Dust bag for a cleaner work environment
• See-through blade guard system for greater visibility of blade and line of cut
• Oversized trigger switch for better fit, added comfort, and easier operation
• Large Cutting Capacity in a Compact Design and Less Weight
• Less weight and compact design for job site portability
• Soft start feature for smooth start-ups
• Ergonomic rubberized D-handle design for better fit and added comfort
• Large precision machined aluminum base supports material for more efficient cutting
• Electric brake for maximum productivity
• Dust bag for a cleaner work environment
• See-through blade guard system for greater visibility of blade and line of cut
• Oversized trigger switch for better fit, added comfort and easier operation
| Bore Size (Arbor Diameter) | 30 mm |
|---|---|
| Capacity 45° (Miter R/L 45°, Bevel 0°) | 91 x 215 mm |
| Capacity 90° | 91 x 310 mm |
| Capacity 45° left (Miter 0°, Bevel L 45°) | 50 x 310 mm |
| Sound Pressure Level | 92 dB(A) |
| Laser Class | 2M |
| Max. Bevel Range (Left) | 45 / 45 º |
| Power Supply Cord | 2,5 m |
| Product Dimensions (L x W x H): | 825 x 536 x 633 mm |
| Continuous Input Power | 1430 W |
| Vibration Uncertainty (K Factor) | 1,5 m/s² |
| Vibration Level (3 axes) | ≤ 2,5 m/s² |
| Sound Power Level (LWA) | 102 dB(A) |
| Weight Without Cable (EPTA) | 19,9 kg |
| Noise Uncertainty (K Factor) | 3 dB(A) |
| Blade Diameter | 260 mm |
| Tool Category | Sawing |
| Bevel capacity right 45° (Miter 0°, Bevel R 45°) | 31 x 310 mm |
| Max. Mitre Range (Left) | 47 / 60 º |
| No load speed | 4300 min⁻¹ |
