Product Description
Lightweight & High Power. BL motor delivers 6,000 RPM for fast cutting. Automatic torque Drive Technology (ADT) adjusts cutting speed and torque during cut for optimum performance. Blinks green to indicate that the tool is overloaded ADT indicator lamp. Compatible with guide rail without adapter. Tool only, battery and charger not included.
User Benefits
- Auto-start Wireless System (AWS) connects to vacuum cleaner with Bluetooth
- Battery protection circuit protects against overloading, over-discharging and over-heating
- Brushless maintenance-free and long-life motor
- Compatible with guide rail without adapter
- Electric brake for maximum productivity and increased operator safety
- Magnesium components create lightweight saws that are well-balanced and jobsite tough
- Twin LED lights with preglow and afterglow functions for better illumination and more accurate work
- XPT (Extreme Protection Technology) is engineered for improved dust and water resistance for operation in harsh job site conditions
| Specification | |
|---|---|
| SOUND POWER LEVEL (LWA) | 104 dB(A) |
| SOUND PRESSURE LEVEL (LPA) | 93 dB(A) |
| NOISE UNCERTAINTY (K FACTOR) | 3 dB(A) |
| VIBRATION LEVEL (3 AXES) | ≤ 2,5 m/s² |
| VIBRATION UNCERTAINTY (K FACTOR) | 1,5 m/s² |
| PRODUCT WEIGHT | 4,4 kg |
| PRODUCT DIMENSIONS (L X W X H): | 337 x 210 x 290 mm |
| EAN | 88381720021 |
| WRENCH | Yes |
| NO LOAD SPEED | 6 000 min⁻¹ |
| BRUSHLESS MOTOR | Yes |
| BATTERY PROTECTION | Yes |
| TOOL WEIGHT WITH BATTERY (EPTA) | 4,4 - 4,7 kg |
| NOMINAL BATTERY VOLTAGE | 40 V |
| BORE SIZE (ARBOR DIAMETER) | 30 mm |
| MAX. CUTTING DEPTH AT 48° | 42 / 41 mm |
| MAX. CUTTING DEPTH AT 90° | 62,5 mm |
| MAX. CUTTING DEPTH AT 45° | 44,5 mm |
| MAX. BEVEL RANGE (LEFT) | 0 / 56 ° |
| BATTERY CHEMISTRY (NI-CD / NI-MH / LI-ION) | Li-ion |
| VOLTAGE XGT | Yes |
| CUTTER | Yes |
| GUIDE RULE | Yes |
| BLADE | 185 / 190 mm |
| AWS READY | Yes |
