Slide Compound Saw
LS1219L
1 800 W • 305 mm • 3 200 min⁻¹
Efficient high-capacity saw with a laser for quick and accurate cutting
An accurate high-capacity mitre saw with a 1 800 W motor for professional use. The dual slide system reduces the need for space, enabling the machine to be placed by a wall. The bevel lock is located at the front of the saw. Equipped with an excellent dust removal function and a built-in laser that indicates line-of-cut.
| Bore Size (Arbor Diameter) | 30 mm |
|---|---|
| Capacity 45° (Miter R/L 45°, Bevel 0°) | 107 x 255 / 92 x 268 mm |
| Capacity 90° | 107 x 363 / 92 x 382 mm |
| Capacity 45° left (Miter 0°, Bevel L 45°) | 71 x 363 / 61 x 382 mm |
| Sound Pressure Level | 91 dB(A) |
| Max. Bevel Range (Left) | 48 / 48 º |
| Laser Class | 2M |
| Power Supply Cord | 2,5 m |
| Product Dimensions (L x W x H): | 898 x 664 x 725 mm |
| Continuous Input Power | 1800 W |
| Vibration Uncertainty (K Factor) | 1,5 m/s² |
| Vibration Level (3 axes) | ≤ 2,5 m/s² |
| Sound Power Level (LWA) | 100 dB(A) |
| Weight Without Cable (EPTA) | 29,5 kg |
| Noise Uncertainty (K Factor) | 3 dB(A) |
| Blade Diameter | 305 mm |
| Tool Category | Sawing |
| Bevel capacity right 45° (Miter 0°, Bevel R 45°) | 54 x 363 / 44 x 382 mm |
| No load speed | 3200 min⁻¹ |
| Max. Mitre Range (Left) | 60 / 60 º |
