Circular Saw XGT
HS009GZ
40V MAX XGT • 4 000 min⁻¹ • 235 mm
XGT® Battery Powered, Efficient circular saw.
40Vmax XGT® Li-ion battery and brushless motor makes this saw excellent choice for demanding applications. The blade can reach up to 4 000 min⁻¹ to ensure high cutting performance. Auto-Start Wireless System function with bluetooth for remote vacuum start. Tool only, battery and a charger not included.
| Max. Cutting Depth at 60° | 44 mm |
|---|---|
| Bore Size (Arbor Diameter) | 15,88 / 25 / 25,4 / 30 mm |
| Tool weight with battery (EPTA) | 5,1 - 6,3 kg |
| Max. Cutting Depth at 45° | 61 mm |
| Capacity 45° (Miter R/L 45°, Bevel 0°) | 61 mm |
| Battery Chemistry (Ni-Cd / Ni-MH / Li-ion) | Li-ion |
| Battery Voltage | 40 V |
| Brushless Motor | YES |
| Sound Pressure Level | 94 dB(A) |
| Product Dimensions (L x W x H): | 413 x 196 x 316 mm |
| Vibration Uncertainty (K Factor) | 1,5 m/s² |
| System | XGT 40Vmax/80V max |
| Vibration Level (3 axes) | ≤ 2,5 m/s² |
| Sound Power Level (LWA) | 105 dB(A) |
| Product net weight (new) | 4,4 kg |
| Voltage XGT | 1 |
| Noise Uncertainty (K Factor) | 3 dB(A) |
| Vacuum cleaner connection Ø in / out | 35/40 mm |
| Blade Diameter | 235 mm |
| Max. Cutting Depth at 90° | 85 mm |
| Max Output Power | 1600 W |
| Tool Category | Sawing |
| AWS FUNCTION | YES |
| No load speed | 4000 min⁻¹ |
• Sold without Battery or Charger
Find available product documentation using the Makita UAE support resources below.
Model: HS009GZ
